Classis Style. Modern Performance
The Nissan® Pathfinder® debuted in 1987 and defined a new era of 2-door sport utility vehicles with its rugged body-on-frame construction, powerful V6 engine, and bold offroad styling. Traxxas honors Pathfinder with a beautifully detailed reproduction mounted on the proven TRX-4® chassis. From the iconic grille and squared-off lines to period-correct badging, TRX-4 Pathfinder captures the spirit of the original Pathfinder with Traxxas performance and durability.
Officially Licensed Replica Body
TRX-4 Pathfinder sets the standard for scale detail in RC crawlers. Classic 80’s style comes back to life with authentic molded details, period-correct badging, and stunning high gloss paint.
|
Clipless Body Mounting
TRX-4 Pathfinder's clipless body mounting system combines clean flowing lines with secure latching convenience. The hidden latches hold tight on the trail no matter how intense the action gets, but release in just seconds to access the chassis.
|
3s Power System
The powerful 3s LiPo-capable XL-5™ HV ESC and 21-turn Titan® motor provide endless torque to tackle the steepest climbs and all-out speed on flat terrain. This efficient system provides up to 2 hours of run time with a Traxxas 3s 5000 mAh LiPo battery pack!
|
The Power of Portals
Portal axles lift the truck at the wheels for huge center pumpkin ground clearance. To achieve the same clearance with straight axles, the tires would have to be over an inch taller than the tires on TRX-4 Pathfinder.
|
Remote Locking Differentials
Traxxas allows you to lock and unlock both the front and rear differentials remotely from your transmitter. New sleeved micro cables control the differential action for scale appearance, without limiting suspension articulation.
|
High/Low Range Transmission
When the going gets tough, engage low range on the TQi transmitter for incredible 4WD pulling torque. Shift into high range for blasting down the trail. TRX-4 Pathfinder adapts to any situation or driving style.
|
Features:
- Officially Licensed Nissan® Pathfinder® Clipless Body
- Clipless body holds tight on the trail, but releases in seconds
- Smooth body lines uninterrupted by body clips
- Scale details: grille, black bumpers, push bar, rear spoiler, side mirrors, door handles, and wipers
- Full composite wheel wells and floor pans
- Trail-tuned XL-5™ HV Waterproof Electronic Speed Control
- Five drive profiles
- Sport Mode — forward / brake / reverse
- Race Mode — forward / brake / no reverse
- Training Mode™ - 50% forward / 100% brake / 50% reverse (patented)
- Trail Mode — forward / brake / reverse / with trail-tuned drag brake in neutral
- Crawl Mode — forward / instant reverse - no neutral with 100% hill holding brake
- Traxxas EZ-Set® one-button setup
- Large, efficient heat sink
- Wide voltage latitude 6–7 cell NiMH, 2–3s LiPo
- Titan® 550 Motor
- Powerful Titan 21T reverse rotation motor with internal cooling fan
- Precision, preset gear mesh adjustments
- Motor retention separate from gear mesh
- Portal Axles
- Increase ground clearance
- Eliminate torque twist
- Steel gears
- Improve axle geometry and reduce strain on driveshafts
- TQi™ 2.4 GHz Radio System
- 4-channel transmitter
- 5-channel micro receiver (6533) with fail-safe security and integrated telemetry ports
- Compatible with optional Traxxas Link Wireless Module (6511) to access full Traxxas Link app functionality (sold separately)
- Automatically stores and loads settings for up to 30 Traxxas Link enabled models
- Exclusive Cruise Control feature for extended trail driving
- Patented waterproof receiver box with easy-access plug
- Rigid Steel Frame
- 1.5 mm thick steel frame rails increase torsional rigidity
- Innovative design allows four wheelbase positions (300 mm, 312 mm, 324 mm, 336 mm)
- Adjustable rear shock tower positions for SWB and LWB configurations
- Rugged rock rails adjust for width
- Wire routing clips integrated into frame rails
- Innovative Battery Compartment
- Hinged battery strap allows quick and easy battery access
- No pins to lose
- Accommodates different height batteries
- Accepts full-size long battery packs
- Integrated compartment accepts smaller 1/16 scale batteries
- Secondary front battery tray accepts smaller 1/16 scale batteries (with optional strap)
- Driveline
- Full-time shaft driven 4-wheel drive
- Tough 6 mm stub axles
- Steel front CV driveshafts
- Hardened steel rear axle shafts
- Remote locking steel gear differentials with cable-actuation
- Steel transfer case gears
- Transmission
- Two speed high/low range with remote shifting
- Dual horizontal shafts
- Twin friction plate slipper clutch
- Easily removed for servicing
- Steering
- Chassis mounted 2075X metal gear digital servo
- Superior 45° steering angle
- Direct steering (no servo saver)
- Steering geometry corrected for bump steer
- Suspension
- Front — 3 link with panhard
- Rear — Triangulated 4 link
- Heavy-duty rod ends with steel hollow balls
- 5 mm diameter steel link rods with 4 mm threaded ends
- Aluminum GTS Shocks
- Oil-filled coilover GTS shocks
- Silver-anodized aluminum bodies
- Threaded bodies with collars easily adjust ride height
- Silky smooth damping for the toughest trails
- O-ring cap seal and dual X-ring shaft seals
- Wheels and Tires
- 1.9" black wheels with chrome beadlock trim
- Pre-mounted 1.9″ Canyon Trail tires with trail-tuned foam inserts
- Trail tuned S1 rubber compound
- 12 mm steel hex
- Sealed Ball Bearings
- Hex hardware with rust-resistant black oxide coating
MODEL 110056-4: TRX-4 Scale and Trail™ crawler with Nissan® Pathfinder® Body: 1/10 scale 4X4 trail truck, fully-assembled, waterproof electronics, Ready-To-Drive®, with TQi™ 2.4 GHz 4-channel radio system, XL-5™ HV speed control, high/low transmission, remote locking differentials, and clipless painted body.
What’s In The Box:
- TRX-4, Ready-To-Race model
- XL-5 HV waterproof electronic speed control
- Titan 21T reverse rotation motor
- TQi 2.4 GHz radio system with cruise control
- High quality maintenance tools
What You’ll Need:
- Batteries
TRX-4 accepts a wide variety of NiMH (4–7 cell) and LiPo (2s–3s) batteries.
- Charger
Traxxas EZ-Peak® Live charger is recommended for easy and fast charging performance (model 2971).
- AA Alkaline Batteries
Four AA alkaline batteries for the transmitter.
Nissan Motor Co., Ltd. trademarks, designs, copyrights and/ or other intellectual property rights are used under license.
