This is the 1/18 scale, 2.4GHz radio controlled, electric powered, ready to run SC18 Short Course Off-Road Race Truck from Associated.
FEATURES: Chassis: Molded composite
Drive: Four wheel, two belt, capable of handling most brushless motor/LiPo combos
Motor: Reedy 5000kV brushless
Radio: Associated 2.4GHz XP3-SS 3-channel with steering and throttle trim, throttle ATV, micro steering servo, transmitter has charge jack
ESC: Associated XPS with reverse
Shocks: Composite body, fluid filled, with adjustable preload
Battery: 6-Cell 1100mah NiMH with micro plug, ASCC0149
Battery Charger: Wall type
Battery Holder: Hinged strap for quick changes
Differential: Planetary gear
Ball Bearings: Full set, shielded, 15 total
Body: Painted and decaled short-course racing truck, 0.03" (0.8mm)
thick polycarbonate
Bumpers: Front and rear composite with rubber rear mud flaps
Wheels: Plastic AMT forged style 1.1" (27mm) diameter, 0.79" (20mm) wide black in color
Tires: Multi-terrain 1.9" (49mm) diameter, 0.87" (22mm) wide
Steering: Dual bellcrank with newly designed servo saver for optimal straight line tracking
INCLUDES: RTR Associated SC18 Short Course Off-Road Race Truck, 3-ch 2.4GHz radio, ESC, painted and trimmed body, NiMH battery, wall charger brushless motor, and instruction manual
REQUIRES: AA Batteries: 8 for transmitter
SPECS: Vehicle-
Length: 10.4" (265mm)
Width: 5.6" (143mm)
Height: 3.5" (89mm)
Wheelbase: 6.5" (166mm)
Track: 5.6" (142mm) outer edges of tires side-to-side
Weight: 1.3lbs (580g)
Internal Gear Ratio: 2.31:1
Body-
Length: 10.5" (268mm)
Width: 4.8" (121mm) behind front wheels, narrowest point
5.8 (147mm) at rear wheels, widest point
Height: 3.1" (80mm)
COMMENTS: For Replacement Ball Bearings use:
Qty. Size Location Qty. Bearing Set
1 8x12x3.5mm Front Diff 1 ASCC0106
1 8x12x3.5mm Rear Diff 1 ASCC0106
1 3x6mm Gearbox 1 DTXC1503
1 4x8mm Spur Gear Pulley 1 DTXC1511
2 4x8mm Caster Blocks 1 DTXC1511
2 8x12x3.5mm Caster Blocks 1 ASCC0106
2 4x8mm Rear Hubs 1 DTXC1511
2 8x12x3.5mm Rear Hubs 1 ASCC0106
