Dixie Nationals Rules




Here you will find the rules for the 2024 Dixie Nationals in all classes.





2024 13.5 MUDBOSS

Body:

  • Template is based on the SALVAS MUDBOSS body so if using a clone it must coincide with the Salvas Mudboss Body Templates to be legal.  Any minor modifications to the body must be approved before being allowed.

Chassis:

  • TRAXXAS 2wd (SLASH or RAPTOR) or TRAXXAS LCG chassis ONLY.
  • Original MFG suspension parts only. No other parts allowed (such as RPM).
  • Original MFG chassis parts only. No aftermarket hop-ups or optional aluminum parts.
  • Front bumper , right side bumper and front body post brace MUST be removed. Left side and rear bumpers can be removed if desired. **Rear RPM BEAR is allowed**
  • TRAXXAS front optional bumper (TRA2735) can be used but must be angled down.
  • Major alterations to the chassis or drivetrain/suspension components not allowed.
  • ALL electronics (receiver, ESC, transponder , etc ) must be mounted within the chassis surface (no outside installation).
  • Battery brace can be trimmed to allow for different MFG LiPo battery wire configurations.

Electronics:

  • Hobbywing locked timing 13.5 motor, part# 30408005 or #30408010 completely in its stock form.
  • A single 30mm motor fan can be used
  • Hobbywing just stock ESC part# 30112000 or 30112003 ONLY.
  • Any servo with a $50 street value or less.
  • Servo saver and / or Bellcrank may be “PINNED”. Be advised the servo gears may be broken in the event of a crash. Only the original TRAXXAS plastic servo saver / bellcrank (white or black system) is allowed to mix components (i.e….black servo horn with white bellcrank).A solid (one piece) servo horn of any brand is allowed.
  • 2 cell LiPo, hardcase, 7.4 volt, hard wired plug (no bullet plug batteries) for connection to the ESC, with a maximum 5200 mah rating and a maximum continuous “C” rating of 50c. No additional batteries are allowed. All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race.  ***We reserve the right to impound and check cells inside hard cases if we deem there is wrong doing or foul play.



Adjustments:

  • TRAXXAS 76/83/86/90 spur gear with all transmission parts in place (slipper).
  • Any size pinion.Motor plate must remain completely stock and un altered. NO SLOTTING to allow larger pinions.
  • NO modifications allowed to the transmission case to allow a bigger gear ratio.
  • Gear cover must be OFF at all times to allow inspection.
  • Transmission functionality rule (motor can not spin while turning slowly 1 rear wheel 1 full turn)
  • TRAXXAS *STEEL* transmission gears only (Internal plastic transmission gears will not be allowed)
  • Any original wheel spacer combination (black , grey or a combo of both).
  • Added weight other than wheel balancing is not allowed.
  • The only allowed adjustments to the car are those allowed by the original MFG components.

Suspension:

  • TRAXXAS 2wd plastic shocks ONLY. (grey or black---front on front , rear on rear). Original springs (front TRA 5858---rear TRA 5857) NO LCG or aftermarket springs allowed. Front springs may be shortened by removing a MAXIMUM of 5 coils.
  • Shocks may use internal limiters to shorten them.
  • Original length shock body and shaft (properly paired. front with front---rear with rear).
  • Original shock pistons from kit (1,2 or 3 hole with NO modifications)
  • NO FRONT BUMPSTOPS. A single original BLUE bumpstop MAY be used on the rear shocks. NO other bumpstops are allowed.
  • No shimming of suspension parts will be allowed.
  • All suspension parts must remain in the original position it was designed for. Upper hole on REAR shock tower for rear camber links is not allowed. Must be in original height position.
  • You can flip the right rear control arm.

Tires: 2024 you can use these tire options:

  • Bandito tires as an option prior to being phased out part number: DTXC3801 SC-M/C3 or DTXC3800 SC-M/C2 with stock, unaltered Bandito foam inserts.
  • Pro-Line Hoosier G-60 in M3 and M4 compounds Part Number: PRO10153-03 and PRO10153-02
  • Pro-Line Hot Lap in M4 and MC compounds Part Number: PRO1023103 and PRO1023117
  • DE Racing Phenom in D30, D40 and Clay compounds Part Number: DER-PSC-D30, DER-PSC-D4- and DER-PSC-C1
  • JConcepts Swiper in Blue or Aqua compounds Part Number: JCO4043-01 and JCO4043-03


Wheels:
Any brand wheel and Offset allowed. Front width can’t exceed 11.75” Rear width can’t exceed 12.25”



2024 12T MUDBOSS

Body:

  • Template is based on the SALVAS MUDBOSS body so if using a clone it must coincide with the Salvas Mudboss Body Templates to be legal.  Any minor modifications to the body must be approved before being allowed.

Chassis:

  • TRAXXAS 2wd (SLASH or RAPTOR) HCG Only - No modification to chassis allowed, it must remain box stock.
  • Original MFG suspension parts only. No other parts allowed (such as RPM).
  • Original MFG chassis parts only. No aftermarket hop-ups or optional aluminum parts.
  • Major alterations to the chassis or drivetrain/suspension components not allowed.
  • ALL electronics (receiver, ESC, transponder , etc ) must be mounted within the chassis surface (no outside installation).
  • Battery brace can be trimmed to allow for different MFG LiPo battery wire configurations.

Electronics:

  • Traxxas 12T Titan brushed motor only (PN:TRA3785)
  • Traxxas XL-5 ESC Only (PN:TRA3018R)

Battery:

  • 2 cell LiPo, hardcase, 7.4 volt, hard wired Dean’s plug (no bullet plug batteries) for connection to the ESC, with a maximum 5200 mah rating and a maximum continuous “C” rating of 50c. No additional batteries are allowed including those used to power receivers or cooling fans. All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race. ***We reserve the right to impound and check cells inside hard cases if we deem there is wrong doing or foul play.

Adjustments:

  • Radio - Stock Radio (No aftermarket radios)
  • Shocks are to remain as the come out of the box. No limiters on the inside or outside of the shocks. Blue bump stops on rear shocks only. May change shock oils. On 1 and 2 hole pistons allowed and all 4 shocks must have the same pistons.
  • White shock springs only and must remain stock. No cutting or altering.
  • Hexes - 2 greys on front and 2 blacks on rear. No deviation.
  • Transmission/Gears: No altering of stock gears internal or external. All to remain stock from the factory with stock bearings.
  • Pinion Gears: 16/21/22/23
  • Spur Gears: 86 or 90
  • Servo must remain stock with stock servo saver. No servo horns. Servo part#2075
  • Tires: Stock Traxxas tires only. All 4 must match and tread must be visible. Fronts on front and rears on rear.
  • Bumpers: Stock rear bumper must be on car. No aftermarket bumpers. Nerf wings must be on car.
  • No aftermarket parts what so ever. Car must remain stock. No aluminum parts are permitted.



2023 SC Modified (Not running in 2023)

Chassis:

  • Must be a SC Based Chassis
  • Carbon fiber chassis allowed. Must meet the following specs. All suspension components, transmission, front and rear bulkheads must be on center line of the vehicle.
  • All larger volume OEM Chassis are legal IE “AE,TLR,Traxxas. Aftermarket or specifically built chassis and kits must conform to the following specifications.
  • Minimum Chassis width 5.125”. Maximum Chassis width 7.0”. Maximum left side of chassis can be from centerline is 3.5”
  • Right side must be a minimum of 2.25” from centerline to outside edge of chassis.
  • Minimum wheelbase 12.5”. Maximum wheelbase 13.5”
  • Shock bodies min length 1”
  • Front Track width Min 11.42”. Max 11.65”
  • Front and Rear Suspension arms must be equal size left and right. Adjustable Rear Suspension arms are allowed.

Motors:

  • OPEN MOTOR

BATTERY:

  • 2 Cell HARD CASE LiPo.
  • Battery must be mounted on the centerline of the vehicle. Can be either designed front to back or sideways across the chassis but center of battery must be on centerline of chassis.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race.
  • No Gyro’s or driving assist devices will be allowed.

TIRES:

  • Any Short Course rubber tire with street type tread or slick (no foam tires). No cutting / gluing tires together

SC OPEN WHEEL MODIFIED BODY RULES:

  • 13" max body width. 28" max length (bumper to spoiler). 7.5" max body height measured from bottom of chassis
  • Center deck: 1" max deck rake. 1" max center deck taper (widest point of the deck can only be 1" wider than the narrowest point of deck)
  • Spoiler: 1.5" max spoiler height Spoiler end plate max 2” high off of center deck and 3.25” long
  • Roof: 0.5” max roof rake measured from deck
  • Maximum Roof width and length 9". No roof spoilers, a bend down at the trailing edge of the roof is allowed for strength
  • Roof side rails allowed but must have a scale appearance and be on both the left and right sides of the roof.
  • 1/4" bend down at the leading edge of the roof allowed.
  • Roll cage/Roof Supports: Must represent a cage, no solid plastic cages, must be cut the same on both sides.
  • Roll cage/roof supports must be cut or formed to resemble a roll cage. No solid panel roof supports. Window netting and rock guards are allowed.
  • Nose: Nose sides can extend a max of .250” above the plane of the nose panel, Nose sides can extend a max of .250” above the plane of the hood panel. Nose cannot extend past the inner edges of the front wheels
  • Main nose panel must be a flat plane. No concave or scooped noses allowed.
  • Rear wheel wells must be cut out to expose ALL of the rear tire and wheel.
  • Left and right windows and sails can be open, but both sides must be the same.





2024 17.5 EDM

 Chassis:

  • EDM’s must resemble contemporary full scale cars racing in “World of Outlaws” and “DIRT” sanctioned events.
  • Wheelbase: 9.5” min, 11.5" max
  • Minimum weight = 53 oz.
  • Maximum width: 10.0”
  • Must be 2 wheel drive (rear wheel driven only)
  • Maximum length of complete car: 19.5"

Motor:

  • Any 17.5 ROAR approved motor may be used.
  • All motors are subject to disassembly at any given time during an event at the race directors discretion.
  • All stators must have 17.5 winds. Stack height may be no less than 19.3 mm tall including all laminations. Wire and turns are subject to be un-wound and examined for correct wire and turns at any time during the event.
  • All motors will be teched by the ROAR Number values on the posted approved list.
  • ROAR Approval for all motors must be approved on or before 9/1/24

Battery:

  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more you do not race.
  • No Gyro’s or driving assist devices will be allowed.

ESC:

  • Any Speed Control from the ROAR Approved Non-Timing ESC list
  • All speedos must be in “blinky” mode during all competition. It is the responsibility of the racer to prove that his ESC is in “blinky” mode.
  • ROAR Approval for all ESC's must be approved on or before 9/1/24

Tires:

  • Foam Tires ONLY.
  • Max wheel diameter: 2.0”
  • Front tire and wheel width: Max 1.1”
  • Rear tire and wheel width: Max 1.5”, Min 1.4"

Bodies:

  • All fabricated body panels I.E. Doors, Windows, Roof, and Inner Panel must be made from minimum .020" thick Lexan/polycarbonate material (.020" measurement does not include any decal or wrap)
  • All Vacuum formed body panels must be pulled from minimum .030" thick Lexan/polycarbonate material. Separate hoods and front body panels may be pulled from .020" Lexan/polycarbonate material
  • No additional wings, flaps, spoilers, wickers or vents will be allowed.
  • Front bumper must be mounted flat and can not be angled to act as a wing.
  • An additional front body panel is allowed on the front of the car but may not extend forward of the front bumper.
  • Max Side lip on front panel and Hood 1/4“
  • Maximum front bumper width: 5.0“
  • Front body panel max width: 4.0“
  • Front body panel max chord length: 3.0"
  • Inner panel must have scale appearing “hood” that extends from the door leading edge to the leading edge of the roof.
  • Said “hood” must be centered on inner panel
  • “Hood” Width: Minimum 2.5"
  • Minimum “hood” height for entire length is: .750“
  • Clearance between top of hood and leading edge of roof is min. 1.0" and max 2.0"
  • Dimensional specifications: See drawing
  • Side panels must be no larger than one of the following three templates: Bicknell Template, Teo Template, Troyer Template See drawings below.
  • Left Side Panel must be inside a straight line drawn from the outside of both left side wheels/tires and outside of left side of chassis.
  • Front and rear windows must be removed and any clear portion is included in max roof length dimension.
  • Side windows must remain clear
  • Both sides of body must be at 90 Degrees to the rear of body and or spoiler
  • Door/side panel may have a 90 degree "BEND IN" max 3/8" at bottom for strength
  • No rear wheel cutouts are allowed on the horizontal plane of the inner. Right and Left rear wheel wells must be cut out to appropriate scale dimensions.
  • Bodies must have at least 1/3 of right rear tire exposed when viewed from front, top and rear of car.
  • Must have 2 side panel braces as specified in drawing that must hold side panels at 90 degrees to inner panel both statically and during racing conditions.
  • Inner panel and spoiler can not extend beyond rear of side panel
  • Outer front edge of inner panel can not extend beyond the front of the door but may taper from that point forward of the door toward the hood at a point no more than 1.5" forward of the door.
  • Roof specifications: Minimum Length and Width 5.25” / Maximum Length and Width 6.25” See drawing
  • Must have rear roof spoiler Min 1/8" Max 1/4" bent DOWN between 45 and 90 degrees
  • Rear spoiler: max chord is 3.0" from body deck including any wicker bills




image003.jpg . image004.jpg . image005.jpg






2024 MOD EDM

 Chassis:

  • EDM’s must resemble contemporary full scale cars racing in “World of Outlaws” and “DIRT” sanctioned events.
  • Wheelbase: 9.5” min, 11.5" max
  • Minimum weight = 53 oz.
  • Maximum width: 10.0”
  • Must be 2 wheel drive (rear wheel driven only)
  • Maximum length of complete car: 19.5"

Motor:

  • Any ROAR approved motor may be used. All motors are subject to disassembly at any given time during an event at the race directors discretion.
  • ROAR Approval for all motors must be approved on or before 9/1/24

Battery:

  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race.
  • No Gyro’s or driving assist devices will be allowed.

ESC:

  • Any Speed Control from the ROAR Approved ESC list
  • ROAR Approval for all ESC's must be approved on or before 9/1/24

Tires:

  • Foam Tires ONLY.
  • Max wheel diameter: 2.0”
  • Front tire and wheel width: Max 1.1”
  • Rear tire and wheel width: Max 1.5”, Min 1.4"

Bodies:

  • All fabricated body panels I.E. Doors, Windows, Roof, and Inner Panel must be made from minimum .020" thick Lexan/polycarbonate material (.020" measurement does not include any decal or wrap)
  • All Vacuum formed body panels must be pulled from minimum .030" thick Lexan/polycarbonate material. Separate hoods and front body panels may be pulled from .020" Lexan/polycarbonate material
  • No additional wings, flaps, spoilers, wickers or vents will be allowed.
  • Front bumper must be mounted flat and can not be angled to act as a wing.
  • An additional front body panel is allowed on the front of the car but may not extend forward of the front bumper.
  • Max Side lip on front panel and Hood 1/4“
  • Maximum front bumper width: 5.0“
  • Front body panel max width: 4.0“
  • Front body panel max chord length: 3.0"
  • Inner panel must have scale appearing “hood” that extends from the door leading edge to the leading edge of the roof.
  • Said “hood” must be centered on inner panel
  • “Hood” Width: Minimum 2.5"
  • Minimum “hood” height for entire length is: .750“
  • Clearance between top of hood and leading edge of roof is min. 1.0" and max 2.0"
  • Dimensional specifications: See drawing
  • Side panels must be no larger than one of the following three templates: Bicknell TemplateTeo TemplateTroyer TemplateSee drawings below.
  • Left Side Panel must be inside a straight line drawn from the outside of both left side wheels/tires and outside of left side of chassis.
  • Front and rear windows must be removed and any clear portion is included in max roof length dimension.
  • Side windows must remain clear
  • Both sides of body must be at 90 Degrees to the rear of body and or spoiler
  • Door/side panel may have a 90 degree "BEND IN" max 3/8" at bottom for strength
  • No rear wheel cutouts are allowed on the horizontal plane of the inner. Right and Left rear wheel wells must be cut out to appropriate scale dimensions.
  • Bodies must have at least 1/3 of right rear tire exposed when viewed from front, top and rear of car.
  • Must have 2 side panel braces as specified in drawing that must hold side panels at 90 degrees to inner panel both statically and during racing conditions.
  • Inner panel and spoiler can not extend beyond rear of side panel
  • Outer front edge of inner panel can not extend beyond the front of the door but may taper from that point forward of the door toward the hood at a point no more than 1.5" forward of the door.
  • Roof specifications: Minimum Length and Width 5.25” / Maximum Length and Width 6.25” See drawing
  • Must have rear roof spoiler Min 1/8" Max 1/4" bent DOWN between 45 and 90 degrees
  • Rear spoiler: max chord is 3.0" from body deck including any wicker bills




image003.jpg . image004.jpg . image005.jpg







2024 17.5 Latemodel Rules



Chassis:

  • Latemodels must resemble contemporary full scale cars racing in “World of Outlaws” and “DIRT” sanctioned events.
  • Minimum weight =53 oz.
  • Wheelbase =9.5” min, 11.5" max.
  • Maximum tread width =10.0”
  • Must be 2 wheel drive, rear wheel driven.

Motor:

  • Any 17.5 ROAR approved motor may be used.
  • All motors are subject to disassembly at any given time during an event at the race directors discretion.
  • All stators must have 17.5 winds. Stack height may be no less than 19.3 mm tall including all laminations. Wire and turns are subject to be un-wound and examined for correct wire and turns at any time during the event.
  • All motors will be teched by the ROAR Number values on the posted approved list.
  • ROAR Approval for all motors must be approved on or before 9/1/24

Battery:

  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more you do not race.
  • No Gyro’s or driving assist devices will be allowed.

ESC:

  • Any Speed Control from the ROAR Approved Non-Timing ESC list
  • All speedos must be in “blinky” mode during all competition. It is the responsibility of the racer to prove that his ESC is in “blinky” mode.
  • ROAR Approval for all ESC's must be approved on or before 9/1/24

Tires:

  • Foam Tires ONLY.
  • Max wheel diameter:
  • 2.0” Front tire and wheel width:
  • Max 1.1” Rear tire and wheel
  • width: Max 1.5”, Min 1.4"


Bodies:

Bodies: The only bodies legal for the Late model class are those that are DODC approved and listed below. Molded portion of body can be no longer than 22”. All corners of bodies and spoilers must be rounded for safety. Under body support may be added to brace each rear quarter panel and door, but must hold it in stock position, cannot be flared out. Must not be wider than 11.50” forward of front wheel openings and 11” at any point behind front wheel openings. No additional wings, flaps, spoilers, wickers or vents will be allowed. Body may not be altered in any way from its DODC approved configuration i.e.: shortened, lengthened, narrowed, flared fenders etc. Front and rear windows may be removed at trim lines but a flat Lexan or similar material deck must be added in cockpit area. Bodies with add on roofs may leave front and rear windows in or out but roofs must be mounted in stock position. On all bodies side and quarter windows must remain in place. All four wheel wells must be cut out to a minimum dimension of 2.50” (see drawing below) . Rear Spoiler maximum chord from body deck including any wicker bills: 2.00“. Maximum rear deck height from bottom of chassis is  4.0" . Rear Spoiler

Cap may not be any larger than the drawing below.



● Custom Works #9070 Keystone Late Model (9.0")
● Custom Works #9071 Buckeye Late Model (9.5")
● Custom Works #9072 Mountaineer Late Model (10.0")
● Factory Works #7353 Rocket Late Model
● Factory Works #7357 Concord Late Model
● JConcepts #0396 L8 Night Late Model
● JConcepts #0425 L8D Decked Late Model Body
● McAllister #207 Tulsa Late Model
● McAllister #250 Vegas Late Model
● McAllister #252 Winchester Late Model
● McAllister #237 Bakersfield Late Model
● McAllister #283 Lernerville Late Model
● McAliister #323 & 323D Fairbury Late Model
● MR Kustoms #18HK030 Hurrikane Late Model (.030 Thick)
● MR Kustoms #18HK040 Hurrikane Late Model (.040 thick)
● MR Kustoms #20HK030 Hurrikane (.030 deck and roof)
● MR Kustoms #20HK040 Hurrikane (.040 deck and .030 roof)
● MR Kustoms #20RD030 Real Deal (.030 deck and roof)
● MR Kustoms #20RD040 Real Deal (.040 deck and .030 roof)
● Protoform #1234-21 Cyclone 9.5 Late Model
● Protoform #1235-21 Cyclone 10.0 Late Model
● Protoform #1238-30 Nor'easter Late Model
● Shark RC (formerly C&M) #2010 Volunteer Late Model
● Shark RC (formerly C&M) #2010-003 Nightmare Late Model
● Shark RC (formerly C&M) #2011-001 Volunteer 10"
● Shark RC (formerly C&M) #2011-002 Nightmare HD 9.5"
● Shark RC #101 Nightmare 2020
● Sippel Speed Shop #LM22 Desperado
● Stalker Bodies #009 Sniper 9 Late Model
● Stalker Bodies #010 Sniper Late Model
● Stalker Bodies #011 Specter 9.5
● Stalker Bodies #012 Specter 10
● Stalker Bodies Specter 9.0
● Stalker Bodies Prowler 10
● Tru-Form Race Products #TRU-12 Kamikazeee









2024 MOD Latemodel Rules (Possibly Adding To Race in 2024)



Chassis:

  • Latemodels must resemble contemporary full scale cars racing in “World of Outlaws” and “DIRT” sanctioned events.
  • Minimum weight =53 oz.
  • Wheelbase =9.5” min, 11.5" max.
  • Maximum tread width =10.0”
  • Must be 2 wheel drive, rear wheel driven.

Motor:

  • Any ROAR approved motor may be used. All motors are subject to disassembly at any given time during an event at the race directors discretion.
  • ROAR Approval for all motors must be approved on or before 9/1/24

Battery:

  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more you do not race.
  • No Gyro’s or driving assist devices will be allowed.

ESC:

  • Any Speed Control from the ROAR Approved ESC list
  • ROAR Approval for all ESC's must be approved on or before 9/1/24

Tires:

  • Foam Tires ONLY.
  • Max wheel diameter:
  • 2.0” Front tire and wheel width:
  • Max 1.1” Rear tire and wheel
  • width: Max 1.5”, Min 1.4"

Bodies:

The only bodies legal for the Late model class are those are listed below. All corners of bodies and spoilers must be rounded for safety. Under body support may be added to brace each rear quarter panel and door, but must hold it in stock position, cannot be flared out. No additional wings, flaps, spoilers, wickers or vents will be allowed. Body may not be altered in any way from its stock configuration i.e.: shortened, lengthened, narrowed, flared fenders etc. Front and rear windows may be removed at trim lines but a flat Lexan or similar material deck must be added in cockpit area. Bodies with add on roofs may leave front and rear windows in or out but roofs must be mounted in stock position. On all bodies side and quarter windows must remain in place.All four wheel wells must be cut out to appropriate scale dimensions.Rear Spoiler maximum chord from body deck including any wicker bills: 2.00“. Maximum rear deck height from bottom of chassis is 4.0".

Rear Spoiler Cap may not be any larger than the drawing below.

•     Custom Works #9016 Paducah 2 Late Model (10.0")
•     Custom Works #9070 Keystone Late Model (9.0")
•     Custom Works #9071 Buckeye Late Model (9.5")
•     Custom Works #9072 Mountaineer Late Model (10.0")
•     McAllister #207 Tulsa Late Model
•     McAllister #250 Vegas Late Model
•     McAllister #252 Winchester Late Model
•     McAllister #237 Bakersfield Late Model
•     MR Kustoms #18HK030 Hurrikane Late Model
•     MR Kustoms #18HK040 Hurrikane Late Model
•     BMS Racing #P103 Shadow
•     Factory Works #7353 Rocket Late Model
•     Factory Works #7357 Concord Late Model
•     C&M Bodies #2010 Volunteer Late Model
•     C&M Bodies #2010-003 Nightmare Late Model
•     C&M Bodies #2011-001 Volunteer 10"
•     C&M Bodies #2011-002 Nightmare HD 9.5"
•     Stalker Bodies #009 Sniper 9 Late Model
•     Stalker Bodies #010 Sniper Late Model
•     Stalker Bodies #011 Specter 9.5
•     Stalker Bodies #012 Specter 10
•     Stalker Bodies Specter 9.0
•     Stalker Bodies Prowler 10
•     Protoform #1234-21 Cyclone 9.5 Late Model
•     Protoform #1235-21 Cyclone 10.0 Late Model
•     Protoform #1238-30 Nor'easter Late Model
•     JConcepts #0396 L8 Night Late Model







2024 21.5 Latemodel Rules



  • Chassis: Latemodels must resemble contemporary full-scale cars racing in “World of Outlaws” and “DIRT” sanctioned events. Minimum weight =53 oz. Wheelbase =9.5” min, 11.5" max. Maximum tread width =10.0” Must be 2-wheel drive, rear wheel driven.


    Motor: The only legal motor for 21.5 Latemodel will be the Motiv USGT Spec motor #GRC2000

    Motor Specifications:

    NO rotors, sensors or stators outside of the below specification provided will be considered legal. Aluminum or stainless-steel main can or end bell screws are prohibited for 21.5 Latemodel competition. Intermixing of parts from ANY manufacturer will not be allowed. No parts of motors may be modified, altered or removed in any way. All stock hardware must be used, I.E. no aluminum or titanium screws/bolts. It is not legal to unwind, rewind, unsolder, re-solder, re-epoxy, add epoxy or any other coating or material to any part of the stator. If the solder tabs are found to be tampered with you will be immediately disqualified. All motors are subject to disassembly at any given time during an event at the race director’s discretion. Removal of stator from outer can, will result in immediate disqualification.



    MOTOR TECH CHECKLIST: MEASUREMENTS TAKEN AT ROOM TEMPERATURE OF 75 DEG F*

    AVERAGE STATOR POLE RESISTANCE: (TOLERANCE 30.0--30.7 ohms)

    AVERAGE TIMING AT 5,000RPM: (TOLERANCE 30--33deg)

    TOTAL SENSOR GAP: (TOLERANCE 0--3deg)

    ROTOR ALIGNMENT: (TOLERANCE 0--5deg)

    ROTOR: Must use stock rotor - USGT logo engraved on shaft


    Gearing: Open


    Battery:
    2 cell LiPo, hardcase, 7.4 volt, hard wired Dean’s plug (no bullet plug batteries) for connection to the ESC, with a maximum 5200 mah rating and a maximum continuous “C” rating of 50c. No additional batteries are allowed including those used to power receivers or cooling fans. All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race. ***We reserve the right to impound and check cells inside hard cases if we deem there is wrong doing or foul play.


    ESC:
    Hobbywing - XR-10 Justock (PN: HWI30112000 or HWI30112003)are the only eligible ESC's completely in its stock form. Only the capacitor that comes with the speed controller may be used. Boosters or anything that adds timing / voltage will not be allowed


    Tires: Foam tires only. Must use BSR Green or Blue / Customworks X2 or X3 compound tires.

    21.5 Latemodel competitors will be allowed a maximum of eight (8) tires for use in competition during the event.

    Competitors will be required to bring tires to tech to be stickered for the event prior to the drivers meeting. Sticker serial numbers will be recorded for each competitor and are non-transferable to other competitors. Only tires stickered for the event will be allowed to be used in competition. At the conclusion of the event, the sticker serial numbers will be void and no longer allowed for use in competition. The tires may be presented for tech and re stickered at other events.



    Front: Max wheel diameter: 2.0” Width: Max 1.1”
    Rear: Max wheel diameter: 2.0” Width: Max 1.5”, Min 1.4“


    Bodies: DODC APPROVED BODIES


  • If you run 21.5 Late Model you can not compete in 17.5 Late Model or any mod class at this Dixie Nationals.







2024 MOD Sprint Car Rules


Chassis:

  • General-Maximum Overall Length: 18.000".
  • Maximum Chassis width: 4.025“.
  • Wheelbase: =9.5” min, 11.5"
  • max. Tread width max 10.0”
  • Weight–Minimum weight is 55oz.

Body/Cage:

  • Cage–Sprint cars must have a scale appearing contemporary cage made out of rounded stock.
  • The cage must be symmetrical left to right and mounted level to the chassis.Unrealistic shaped cages designed to exploit the rules below are not permitted.
  • Maximum cage width at driver halo, down tubes, and top frame rail: 3.600".
  • Maximum cage height 5.5" from top of chassis to top of cage at highest point.
  • All cage and body components such as cage, bumpers, nerf bars, hoods, side panels, tanks, etc. must be mounted on the centerline of the cage.
  • Chassis may not extend outside of the side panels by more than 1/4" on either side.
  • Bumpers–A flat, curved or tubular front bumper (or combination of) must be used and may not be designed to direct air or create downforce.
  • Maximum height of front bumper is 1.75” from the bottom of the lowest point of the chassis.
  • Scale appearing side nerf bars must be used on both sides of the car (left side of nitro sprint is optional due to clearance needed for nitro exhaust).
  • A scale appearing rear hoop style bumper must be used.
  • Bumpers and nerf bars must be made of rounded stock with no sharp edges.
  • Tail tank–A traditional scale appearing rounded style three dimensional rear fuel cell must be used.
  • Headers-Three dimensional scale appearing exhaust headers must appear on both sides of car in “engine area” Cage Side panels–Flat side panels may be made from molded or fabricated polycarbonate.
  • Maximum height of side panels in front of the driver cockpit is 3.80” from the bottom of the chassis.
  • Must have minimum of3/4" high by 2.5" long openings on both sides of cage in driver compartment.
  • Additional material may be used/added to either side of the side panel openings to replicate a scale appearing driver but may not exceed 1" x 1".(Note that the top wing mounts may cover these openings for winged classes.)
  • Side panels may not extend beyond the rear of the cage by more than 0.25”.Side panels may not extend above or in front of the front down tubes.
  • Scale appearing driver arm guards and engine vents may be used but cannot extend more than 3/8" from the side panels.
  • No other flares or turnouts designed to deflect, trap and/or form a pattern for air to travel in a directed manner are permitted except for those used to cool electronics.
  • HoodArea–A scale appearing hood must be used and is defined as beginning at the front axle and ending at the front of the driver cockpit.
  • The hood must be symmetrical from left to right.
  • The hood must be tall enough and wide enough to allow room for a scale engine intake and air cleaners (no unrealistically low or flat hoods).
  • Minimum vertical gap from top of hood to bottom of front cage crossbar: .750".
  • The hood may not drop below the nearest point of the side panels by more than 3/8” and may not have any channels more than 0.25” deep designed to trap or direct air.
  • Nose Area–A molded or fabricated nose piece may be used and is defined from the front axle forward to the front bumper.
  • Front bumper may not extend more than 3” from front axles.
  • Nose piece (any Lexan) must be at least 3/8" back from the leading edge of the front bumper.
  • Maximum width of nose piece/bumper is 3.75". Maximum width of any surface designed to add downforce is 3.125”.
  • Nose piece may not extend above the cage down tubes or an imaginary line connecting the down tubes if the cage is a split design.
  • Front wing/mounts–For front wing dimensions see appropriate wing drawing pdf.
  • The front wing center section may not extend in front of the front bumper.
  • Front wing mounts may be made of Lexan but may not exceed 1.75” in length and 1.75” in height and may not extend in front of or behind the center section of the wing.
  • Top wing/mounts–For top wing dimensions see appropriate wing drawing pdf.
  • The 6x6" main wing deck will be the standard Sprint Car wing size.
  • Top wings are mandatory and front wings are optional.
  • Top wing height at leading edge: 5.00“minimum / 6.5” maximum from bottom of chassis.
  • Center section and side panels must be made from at least 3 separate pieces of polycarbonate, carbon or aluminum material.
  • All corners and edges must be rounded and free of sharp edges.
  • Main and Front wings must be mounted so that they are centered on cage, no offset wings.
  • Wing center sections must have all 4 corners set at 90 degree angles, no canted or angled panels.
  • Wings must also be mounted level from side to side.
  • Center section of wing may not extend beyond leading or trailing edge of side panels.
  • Side panels must have braces that hold side panel rigid at 90deg. to center section during race conditions.
  • Two braces are required from top of the center foil to the left sideboard and one brace is permitted below the center foil to the right side board.
  • Braces can be a maximum of .750" wide and front edge of front brace must be no more than 1.5” back from side panel leading edge.
  • Side Panels may have front, back, top and bottom turnouts of no more than .375" and are included in max dimension.
  • Flat foil center sections will be allowed a .250” turndown at the leading edge.

Tires:

  • Foam Tires ONLY.
  • Max wheel diameter:
  • 2.0” Front tire and wheel width:
  • Max 1.1” Rear tire and wheel
  • width: Max 1.5”, Min 1.4"

Motor:

  • Any ROAR approved motor may be used. All motors are subject to disassembly at any given time during an event at the race directors discretion.
  • ROAR Approval for all motors must be approved on or before 9/1/24

Battery:

  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less.  If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race.
  • No Gyro’s or driving assist devices will be allowed.

ESC:

  • Any Speed Control from the ROAR Approved ESC list
  • ROAR Approval for all ESC's must be approved on or before 9/1/24

srp-1.jpg  srp-2.jpg









2024 17.5 Sprint Car



Chassis:

  • General-Maximum Overall Length: 18.000".
  • Maximum Chassis width: 4.025“.
  • Wheelbase: =9.5” min, 11.5"
  • max. Tread width max 10.0”
  • Weight–Minimum weight is 55oz.

Body/Cage:

  • Cage–Sprint cars must have a scale appearing contemporary cage made out of rounded stock.
  • The cage must be symmetrical left to right and mounted level to the chassis.Unrealistic shaped cages designed to exploit the rules below are not permitted.
  • Maximum cage width at driver halo, down tubes, and top frame rail: 3.600".
  • Maximum cage height 5.5" from top of chassis to top of cage at highest point.
  • All cage and body components such as cage, bumpers, nerf bars, hoods, side panels, tanks, etc. must be mounted on the centerline of the cage.
  • Chassis may not extend outside of the side panels by more than 1/4" on either side.
  • Bumpers–A flat, curved or tubular front bumper (or combination of) must be used and may not be designed to direct air or create downforce.
  • Maximum height of front bumper is 1.75” from the bottom of the lowest point of the chassis.
  • Scale appearing side nerf bars must be used on both sides of the car (left side of nitro sprint is optional due to clearance needed for nitro exhaust).
  • A scale appearing rear hoop style bumper must be used.
  • Bumpers and nerf bars must be made of rounded stock with no sharp edges.
  • Tail tank–A traditional scale appearing rounded style three dimensional rear fuel cell must be used.
  • Headers-Three dimensional scale appearing exhaust headers must appear on both sides of car in “engine area” Cage Side panels–Flat side panels may be made from molded or fabricated polycarbonate.
  • Maximum height of side panels in front of the driver cockpit is 3.80” from the bottom of the chassis.
  • Must have minimum of3/4" high by 2.5" long openings on both sides of cage in driver compartment.
  • Additional material may be used/added to either side of the side panel openings to replicate a scale appearing driver but may not exceed 1" x 1".(Note that the top wing mounts may cover these openings for winged classes.)
  • Side panels may not extend beyond the rear of the cage by more than 0.25”.Side panels may not extend above or in front of the front down tubes.
  • Scale appearing driver arm guards and engine vents may be used but cannot extend more than 3/8" from the side panels.
  • No other flares or turnouts designed to deflect, trap and/or form a pattern for air to travel in a directed manner are permitted except for those used to cool electronics.
  • HoodArea–A scale appearing hood must be used and is defined as beginning at the front axle and ending at the front of the driver cockpit.
  • The hood must be symmetrical from left to right.
  • The hood must be tall enough and wide enough to allow room for a scale engine intake and air cleaners (no unrealistically low or flat hoods).
  • Minimum vertical gap from top of hood to bottom of front cage crossbar: .750".
  • The hood may not drop below the nearest point of the side panels by more than 3/8” and may not have any channels more than 0.25” deep designed to trap or direct air.
  • Nose Area–A molded or fabricated nose piece may be used and is defined from the front axle forward to the front bumper.
  • Front bumper may not extend more than 3” from front axles.
  • Nose piece (any Lexan) must be at least 3/8" back from the leading edge of the front bumper.
  • Maximum width of nose piece/bumper is 3.75". Maximum width of any surface designed to add downforce is 3.125”.
  • Nose piece may not extend above the cage down tubes or an imaginary line connecting the down tubes if the cage is a split design.
  • Front wing/mounts–For front wing dimensions see appropriate wing drawing pdf.
  • The front wing center section may not extend in front of the front bumper.
  • Front wing mounts may be made of Lexan but may not exceed 1.75” in length and 1.75” in height and may not extend in front of or behind the center section of the wing.
  • Top wing/mounts–For top wing dimensions see appropriate wing drawing pdf.
  • The 6x6" main wing deck will be the standard Sprint Car wing size.
  • Top wings are mandatory and front wings are optional.
  • Top wing height at leading edge: 5.00“minimum / 6.5” maximum from bottom of chassis.
  • Center section and side panels must be made from at least 3 separate pieces of polycarbonate, carbon or aluminum material.
  • All corners and edges must be rounded and free of sharp edges.
  • Main and Front wings must be mounted so that they are centered on cage, no offset wings.
  • Wing center sections must have all 4 corners set at 90 degree angles, no canted or angled panels.
  • Wings must also be mounted level from side to side.
  • Center section of wing may not extend beyond leading or trailing edge of side panels.
  • Side panels must have braces that hold side panel rigid at 90deg. to center section during race conditions.
  • Two braces are required from top of the center foil to the left sideboard and one brace is permitted below the center foil to the right side board.
  • Braces can be a maximum of .750" wide and front edge of front brace must be no more than 1.5” back from side panel leading edge.
  • Side Panels may have front, back, top and bottom turnouts of no more than .375" and are included in max dimension.
  • Flat foil center sections will be allowed a .250” turndown at the leading edge.

Tires:

  • Foam Tires ONLY.
  • Max wheel diameter:
  • 2.0” Front tire and wheel width:
  • Max 1.1” Rear tire and wheel
  • width: Max 1.5”, Min 1.4"

Motor:

  • Any 17.5 ROAR approved motor may be used.
  • All motors are subject to disassembly at any given time during an event at the race directors discretion.
  • All stators must have 17.5 winds. Stack height may be no less than 19.3 mm tall including all laminations. Wire and turns are subject to be un-wound and examined for correct wire and turns at any time during the event.
  • All motors will be teched by the ROAR Number values on the posted approved list.
  • ROAR Approval for all motors must be approved on or before 9/1/24

Battery:

  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race.
  • No Gyro’s or driving assist devices will be allowed.

ESC:

  • Any Speed Control from the ROAR Approved Non-Timing ESC list
  • All speedos must be in “blinky” mode during all competition. It is the responsibility of the racer to prove that his ESC is in “blinky” mode.
  • ROAR Approval for all ESC's must be approved on or before 9/1/24







srp-1.jpg  srp-2.jpg








2024 Rubber Tire Sprint Car



This class is intended to let our loose dirt fellow racers enjoy the fun on the wet packed clay tracks and other tracks other than loose dirt.

Chassis:

  • No purpose built or OEM high bite cars are allowed in this class.
  • Loose dirt cars only (Purpose built or conversion cars)
  • Gearbox transmission only.
  • Must use same length dog bones on both side of transmission.

Body/Cage:

  • DODC Body Rules Apply
  • 7x7 top wing only. Front wing doesn’t matter.

Tires:

  • Open Tires
  • Tires must be mounted on standard front and rear 2.2 wheels.
  • Inserts can be punched or altered.
  • No banding or taping of the inside of the tires to prevent growth or ballooning.

Motor:

  • Any ROAR approved motor may be used.
  • All motors are subject to disassembly at any given time during an event at the race directors discretion.
  • ROAR Approval for all motors must be approved on or before 9/1/24

Battery:

  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race.
  • No Gyro’s or driving assist devices will be allowed.

ESC:

  • Any Speed Control from the ROAR Approved ESC list
  • ROAR Approval for all ESC's must be approved on or before 9/1/24






2024 Rubber Tire Late Model

Chassis:

  • Must be Loose Dirt Late Model Chassis or LateModel Buggy Conversion.
  • 2wd and Rear Wheel drive only
  • No front brakes allowed
  • Wheel base 9.5" min and 11.5" max.
  • No straight axles.
  • Maximum width: 10.250"

Suspension:

  • Car must have 4-wheel independent suspension.

Transmission:

  • Must have transmission, no direct drive allowed.

Steering:

  • Open servo
  • Open Radio
  • No Gyros or assist devices
  • No additional batteries for receiver, transponder etc...

MOTOR:

  • Hobbywing 10.5 Locked Timing (#30408009)

ESC

  • Hobbywing just stock ESC (#30112000 or 30112003)

Battery:

  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race.
  • No Gyro’s or driving assist devices will be allowed.

Tires/Wheels:

  • Open Tire
  • Tires must be mounted on standard front and rear 2.2 wheels.
  • Inserts can be punched or altered.
  • No banding or taping of the inside of the tires to prevent growth or ballooning.

Bodies:

  • Any 1/10 DODC Approved Late Model Body.
  • All side windows must remain
  • Max 2.5" Spoiler allowed
  • Body braces may be used however no flaring.
  • No additional wings, flaps, spoilers, wickers, vents or doohickeys will be allowed. Body may not be altered in anyway from the stock configuration.
  • All four wheel wells must be cut out to the appropriate scale dimensions.
  • Max deck height from bottom of chassis is 4"

Weight:

  • Car (ready to race) must weigh a minimum of 55oz.
  • All power, electronics and weights must be in a secure and fixed position not removeable during a race. Loss of weight could result in post race DQ.



***This is a new class and rules can be altered and changed in the interest of fairness and competition.





2024 SUPER STREET





Body:

  • All Production 1/8/SC Street Stock Bodies permitted.
  •  1” Max Spoiler & Side Dam Height from Deck Lid.

Chassis: Stock TRAXXAS HCG Chassis Only.  No LCG Chassis allowed. No cutting or altering of chassis allowed.

Electronics:

  • Hobbywing locked timing 13.5 motor, part# 30408005 or #30408010 completely in its stock form.
  • A single 30mm motor fan can be used
  • Hobbywing just stock ESC part# 30112000 or HWI30112003 ONLY.
  • Servo must be below $50 price at any retailer MAP price.
  • 2 cell LiPo, hardcase, 7.4 volt, hard wired plug (no bullet plug batteries) for connection to the ESC, with a maximum 5200 mah rating and a maximum continuous “C” rating of 50c. No additional batteries are allowed.  All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less. If the battery reads 8.45 or more on the SCOR Volt meter you will be required to run your battery down to 8.35 prior to entering the race. ***We reserve the right to impound and check cells inside hard cases if we deem there is wrong doing or foul play.

Gearing:

  • Spur: 86 48P (Traxxas Only)
  • Pinion: 25-26-27 48P
  • Tech and Race Director reserves the right to change the gearing options on a track to track basis.

Suspension:

  • TRAXXAS 2wd plastic shocks ONLY. (grey or black---front on front , rear on rear). (Factory Only)
  • Shocks may use internal limiters to shorten them.
  • Original length shock body and shaft (properly paired. front with front---rear with rear).
  • Original shock pistons from kit (1,2 or 3 hole with NO modifications)
  • Any spring combo is allowed.
  • No shimming of suspension parts will be allowed.
  • All suspension parts must remain in the original position it was designed for. Upper hole on REAR shock tower for rear camber links is not allowed. Must be in original height position.
  • You can flip the right rear arm.
  • 4x4 Bellcrank system is not allowed.
  • Traxxas Aluminum shock caps are allowed.

Transmission:

  • Must remain stock from factory.

Tires:

  • Bandito tires as an option prior to being phased out part number: DTXC3801 SC-M/C3 or DTXC3800 SC-M/C2 with stock, unaltered Bandito foam inserts.
  • Pro-Line Hoosier G-60 in M3 and M4 compounds Part Number: PRO10153-03 and PRO10153-02
  • Pro-Line Hot Lap in M4 and MC compounds Part Number: PRO1023103 and PRO1023117
  • DE Racing Phenom in D30, D40 and Clay compounds Part Number: DER-PSC-D30, DER-PSC-D4- and DER-PSC-C1
  • JConcepts Swiper in Blue or Aqua compounds Part Number: JCO4043-01 and JCO4043-03

Wheels: Any brand wheel and Offset allowed. Front width can’t exceed 11.75” Rear width can’t exceed 12.25”






2024 Midget

General:

  • Maximum Overall Length: 16.750”. Maximum Chassis width: 4.2”. Maximum of 4 shocks can be used. Solid axles are allowed. If solid axles are used the rear axle must be square with centerline of the chassis and parallel to the front axle

Wheelbase:

  • Min 9.5” Max 10.0”

Width:

  • Min 8.5” Max 10.0”

Rear Toe:

  • Only non adjustable rear arms can be used. Trackside toe adjustable rear hubs and or arms are not allowed. Trackside adjustable wheelbase is not allowed (can’t have toe blocks or anything else attached to an easily adjustable mechanism to allow for wheelbase change trackside). Left rear can be toed in via toe block. Right rear can be toed in but can Not be toed out.

Offset:

  • Right side of cage can be no further offset from the outside of the RR tire than 3.625”

Ballast Weight:

  • Brass, tungsten or steel hubs, arms, arm inserts, caster blocks, steering arms are not allowed. Ballast weight is allowed to be attached to the main chassis area as long as it’s secured properly.

Transmission:

  • 3 gear transmissions only. No DD, 2, 4 or 5 gear transmissions will be allowed. All gears must be full gears. No narrowed or lightened gears allowed. Plastic, Aluminum and steel gears are permitted. Steel outdrives only. Blades are permitted. No gear diffs allowed. No rear motor cars allowed unless you can do it in a manner that the tail tank is appropriately sized and located.

Solid Axle Option:

  • If a solid rear axle is used, the motor must be mounted to the chassis and cva/cvd must be used to drive the rear axle. No belts or chains will be allowed. A spur gear and pinion must be used in conjunction with the motor plate mounted to the chassis

CVA/CVD:

  • Dog bones must be equal length. Axles and bones must be made from steel. No aluminum, titanium or magnesium axles or bones allowed.

Motor:

  • Hobbywing locked timing 13.5 motor, part# 30408005 or #30408010 completely in its stock form.
  • Aluminum or stainless-steel main can or end bell screws are prohibited for competition. Intermixing of parts from ANY manufacturer will not be allowed. No parts of motors may be modified, altered or removed in any way. All stock hardware must be used, I.E. no aluminum or titanium screws/bolts. It is not legal to unwind, rewind, unsolder, re-solder, re-epoxy, add epoxy or any other coating or material to any part of the stator. If the solder tabs are found to be tampered with you will be immediately disqualified. All motors are subject to disassembly at any given time during an event at the race director’s discretion. Removal of stator from outer can, will result in immediate disqualification.
  • Average motor resistance between two phases (AB, BC, AC) may not be below 27.3 at 77*F/25*C
  • Average timing at 5,000 RPM may not exceed 48 degrees timing

Electronics:

  • A single 30mm motor fan can be used to cool the motor.
  • Hobbywing just stock ESC part# 30112000 or HWI30112003 ONLY.
  • Any 2 cell hard cased lipo battery may be used.
  • No additional batteries are allowed including those used to power receivers or cooling fans.
  • All batteries will be checked prior to each race to ensure battery voltage is a maximum of 8.44 volts or less.
  • No Gyro’s or driving assist devices will be allowed.

Tires: (Subject to change) *8/13/24

  • Raw Speed Slick
  • JConcepts Smoothie 2
  • Pro-Line Bald Eagle
  • DE Phenom
  • Quasi Speed Low Pin
  • No cutting, grooving, or modifying the size and shape of the tire is permitted

Cage:

  • Must have a scale appearing contemporary cage made out of rounded stock. The cage must be symmetrical left to right and mounted level to the chassis. Unrealistic shaped cages designed to exploit the rules below are not permitted. Maximum cage width at driver halo, down tubes, and top frame rail: 3.600”. Minimum cage height is 6.00” while maximum cage height 6.25” from top of chassis to top of cage at highest point. Rear “down tubes” must slant forward. All cade and body components such as cage, bumpers, nerf bars, hoods, side panels, tanks, etc. must be mounted on the centerline of the cage. Chassis may not extent outside of the side panels by more than ¼” on either side.

Bumpers:

  • A tubular front bumper must be used and may not be designed to direct air or create downforce. Maximum height of front bumper is 1.5” from the bottom of the lowest point of the chassis. Scale appearing side nerf bars must be used on both sides of the car. A scale appearing rear hoop style rear bumper must be used. Bumpers and nerf bars must be made of rounded stock with no sharp edges.


Tail Tank:

  • A traditional scale appearing rounded style three dimensional rear fuel cell must be used. A rectangle (Swindell) style rear tank is allowed but must have the proper style rear bumper to go with it. You cannot simply have a flat tail section with no bumper.
  • Headers
  • Three dimensional scale appearing headers must be used on the left side of the car in “engine area”. Material must be plastic or aluminum. Not allowed to make inserts for these to add ballast weight.
  • Side Panels
  • Flat side panels may be made from molded or fabricated polycarbonate. Maximum height of side panels in front of driver cockpit is 4.50” from the bottom of the chassis. Must have minimum of ½” high by 2.5” long openings on both sides of cage in driver compartment. Additional material may be used/added to either side of the side panel openings to replicate a scale appearing driver but may not exceed 1”x1”. Side panels may not extend beyond the cage by more than 0.25”. Side Panels may not extend into the area that is behind the rear axle AND below the top of the rear nerf bar. Scale appearing driver arm guard and engine vents may be used but cannot extend more than ⅜” from the side panels. No other flares or turnouts designed to deflect, trap and/or form a pattern for air to travel in a directed manner are permitted except for those used to cool electronics.

Hood:

  • A scale appearing hood must be used and is defined as beginning at the point where torsion tubes or cross brace would be on a 1:1 car behind the front bumper. The hood must be tall enough and wide enough to allow room for a scale engine intake and air cleaners (no unrealistically low or flat hoods). Minimum vertical gap from top of hood to bottom of front cage crossbar.

Nose Area:

  • No molded or fabricated nose piece may be used and is defined from the torsion tube or cross brace would be on a 1:1 car. You cannot have anything below that point that is on the same plane as the hood. No scoops or bodywork allowed in this area. You can have side panels along the front of the cage but they cannot stick past the cage sides



Free Shipping On $100 Orders
Rewards Program
Secure Shopping

The cookie settings on this website are set to 'allow all cookies' to give you the very best experience. Please click Accept Cookies to continue to use the site.
